R-1W
Radial Agricultural Tyres
Construction RADIAL
Service Tractor Service
The cut-resistant compound brings much more stabilityto the tire and improve vehicle safety
The tread pattern ensures excellent self-cleaning abilityand better grip.
Outstanding productivity thanks to high speed design on 65km/h
| Size | Load index | Speed index | IND | Rim | Section width | Ovearall diameter | Load capacity | Inflation pressure | Tread depth | Type | ||||
| mm | inch | mm | inch | kg | kPa | psi | mm | 32nds | ||||||
| 440/65R24 | 128/131 | D/A8 | R-1W | W14L | 441 | 17.4 | 1182 | 46.5 | 1800 | 160 | 23 | 45 | 57 | TL |
| 440/65R28 | 131/134 | D/A8 | R-1W | W14L | 441 | 17.4 | 1283 | 50.5 | 1950 | 160 | 23 | 45 | 57 | TL |
| 480/65R24 | 133/136 | D/A8 | R-1W | W15L | 479 | 18.9 | 1234 | 48.6 | 2060 | 160 | 23 | 46 | 58 | TL |
| 480/65R28 | 136/139 | D/A8 | R-1W | W15L | 479 | 18.9 | 1335 | 52.6 | 2240 | 160 | 23 | 46 | 58 | TL |
| 540/65R24 | 140/143 | D/A8 | R-1W | W16L | 550 | 21.7 | 1312 | 51.7 | 2500 | 160 | 23 | 48 | 60 | TL |
| 540/65R28 | 142/145 | D/A8 | R-1W | W16L | 550 | 21.7 | 1413 | 55.6 | 2650 | 160 | 23 | 48 | 60 | TL |
| 540/65R30 | 150/153 | D/A8 | R-1W | W16L | 550 | 21.7 | 1464 | 57.6 | 3350 | 240 | 35 | 48 | 60 | TL |
| 540/65R34 | 145/148 | D/A8 | R-1W | W16L | 550 | 21.7 | 1566 | 61.7 | 2900 | 160 | 23 | 48 | 60 | TL |
| 540/65R38 | 153/156 | D/A8 | R-1W | W16L | 550 | 21.7 | 1667 | 65.6 | 3650 | 240 | 35 | 48 | 60 | TL |
| 600/65R28 | 147/150 | D/A8 | R-1W | DW20B | 591 | 23.3 | 1491 | 58.7 | 3075 | 160 | 23 | 52 | 66 | TL |
| 600/65R34 | 157/160 | D/A8 | R-1W | DW20B | 591 | 23.3 | 1644 | 64.7 | 4125 | 240 | 35 | 52 | 66 | TL |
| 600/65R38 | 153/156 | D/A8 | R-1W | DW20B | 591 | 23.3 | 1745 | 68.7 | 3650 | 160 | 23 | 52 | 66 | TL |
| 650/65R38 | 157/160 | D/A8 | R-1W | DW20B | 645 | 25.4 | 1811 | 71.3 | 4125 | 160 | 23 | 56 | 71 | TL |
| 650/65R42 | 165/168 | D/A8 | R-1W | DW20B | 645 | 25.4 | 1913 | 75.3 | 5150 | 240 | 35 | 56 | 71 | TL |
| 710/70R38 | 166/169 | D/A8 | R-1W | DW23B | 716 | 28.2 | 1959 | 77.1 | 5300 | 160 | 23 | 57 | 72 | TL |
| 710/70R42 | 168/171 | D/A8 | R-1W | DW23B | 716 | 28.2 | 2061 | 81.1 | 5600 | 160 | 23 | 57 | 72 | TL |
| 710/70R42 | 173/176 | D/A8 | R-1W | DW23B | 716 | 28.2 | 2061 | 81.1 | 6500 | 240 | 35 | 57 | 72 | TL |
