R-1W
Radial Agricultural Tyres
Construction RADIAL
Service Harvester Service
Lower aspect ratio design brings better response ondriving, and provides better traction
Higher tensile steel cords with a special pattern design inthe tread rubber increase tire lifetime
Longer tire life due to the optimized tread pattern designand cut resistance compound
| Size | Load index | Speed index | IND | Rim | Section width | Ovearall diameter | Load capacity | Inflation pressure | Tread depth | Type | ||||
| mm | inch | mm | inch | kg | kPa | psi | mm | 32nds | ||||||
| 600/70R28 | 157 | D | R-1W | DW20B | 591 | 23.3 | 1551 | 61.1 | 4125 | 240 | 35 | 52.5 | 66 | TL |
| 600/70R28 | 161/161 | A8/B | R-1W | DW20B | 591 | 23.3 | 1551 | 61.1 | 4625 | 280 | 41 | 52.5 | 66 | TL |
| 600/70R30 | 152 | D | R-1W | DW20B | 591 | 23.3 | 1602 | 63.1 | 3550 | 160 | 23 | 52.5 | 66 | TL |
| 600/70R30 | 158 | D | R-1W | DW20B | 591 | 23.3 | 1602 | 63.1 | 4250 | 240 | 35 | 52.5 | 66 | TL |
| 620/70R42 | 172 | D | R-1W | DW20B | 625 | 24.6 | 1935 | 76.2 | 6300 | 320 | 46 | 58 | 73 | TL |
| 650/85R38 | 173/176 | D/A8 | R-1W | DW23B | 645 | 25.4 | 2071 | 81.5 | 6500 | 240 | 35 | 65 | 82 | TL |
| 600/70R34 | 160/163 | D/A8 | R-1W | DW20B | 601 | 23.7 | 1704 | 67.1 | 4500 | 240 | 35 | 52 | 66 | TL |
| 650/60R34 | 159/162 | D/A8 | R-1W | DW20B | 645 | 25.4 | 1644 | 64.7 | 4375 | 240 | 35 | 52 | 66 | TL |
| 710/55R30 | 153/156 | D/A8 | R-1W | DW23B | 706 | 27.8 | 1544 | 60.8 | 3650 | 160 | 23 | 51 | 64 | TL |
| 710/75R42 | 181/184 | D/A8 | R-1W | DW23B | 706 | 27.8 | 2133 | 84.0 | 8250 | 320 | 46 | 63 | 79 | TL |
| 800/70R38 | 178/181 | D/A8 | R-1W | DW25B | 798 | 31.4 | 2085 | 82.1 | 7500 | 240 | 35 | 62 | 78 | TL |
