I-3
Radial Agricultural Tyres
Construction RADIAL
Service Floater And Implement Service
The larger contact area offers significant flotation andsoil protection
Special tread design and unique pattern improve vehiclesafety
| Size | Load index | Speed index | IND | Rim | Section width | Ovearall diameter | Load capacity | Inflation pressure | Tread depth | Type | ||||
| mm | inch | mm | inch | kg | kPa | psi | mm | 32nds | ||||||
| 500/50R17 IMP | 149 | D | I-3 | 16.00 | 503 | 19.8 | 932 | 36.7 | 3250 | 500 | 73 | 15 | 19 | TL |
| 500/45R22.5 IMP | 146 | D | I-3 | AG16.00 | 503 | 19.8 | 1022 | 40.2 | 3000 | 400 | 58 | 21 | 26 | TL |
| 500/60R22.5 IMP | 155 | D | I-3 | AG16.00 | 503 | 19.8 | 1172 | 46.1 | 3875 | 400 | 58 | 18 | 23 | TL |
| 560/45R22.5 IMP | 152 | D | I-3 | AG16.00 | 543 | 21.4 | 1076 | 42.4 | 3550 | 400 | 58 | 18 | 23 | TL |
| 560/60R22.5 IMP | 165 | D | I-3 | AG16.00 | 543 | 21.4 | 1244 | 49.0 | 5150 | 500 | 73 | 18 | 23 | TL |
| 580/65R22.5 IMP | 166 | D | I-3 | AG18.00 | 577 | 22.7 | 1326 | 52.2 | 5300 | 400 | 58 | 21 | 26 | TL |
| 600/50R22.5 IMP | 163 | D | I-3 | AG18.00 | 591 | 23.3 | 1172 | 46.1 | 4875 | 500 | 73 | 21 | 26 | TL |
| 600/55R26.5 IMP | 165 | D | I-3 | AG20.00 | 591 | 23.3 | 1333 | 52.5 | 5150 | 400 | 58 | 20 | 25 | TL |
| 650/55R26.5 IMP | 169 | D | I-3 | AG20.00 | 645 | 25.4 | 1389 | 54.7 | 5800 | 400 | 58 | 24 | 30 | TL |
| 650/65R26.5 IMP | 174 | D | I-3 | AG20.00 | 645 | 25.4 | 1519 | 59.8 | 6700 | 400 | 58 | 24 | 30 | TL |
| 710/50R26.5 IMP | 170 | D | I-3 | AG24.00 | 727 | 28.6 | 1383 | 54.4 | 6000 | 400 | 58 | 24 | 30 | TL |
| 710/50R30.5 IMP | 173 | D | I-3 | AG24.00 | 727 | 28.6 | 1485 | 58.5 | 6500 | 400 | 58 | 26 | 33 | TL |
| 750/45R26.5 IMP | 170 | D | I-3 | AG24.00 | 754 | 29.7 | 1349 | 53.1 | 6000 | 400 | 58 | 25 | 31 | TL |
| 750/60R30.5 IMP | 181 | D | I-3 | AG24.00 | 754 | 29.7 | 1675 | 65.9 | 8250 | 400 | 58 | 26 | 33 | TL |
| 800/45R26.5 IMP | 174 | D | I-3 | AG26.00 | 808 | 31.8 | 1393 | 54.8 | 6700 | 400 | 58 | 26 | 33 | TL |
| 800/45R30.5 IMP | 176 | D | I-3 | AG26.00 | 808 | 31.8 | 1495 | 58.9 | 7100 | 400 | 58 | 26 | 33 | TL |
