E-3/L-3
Radial Off-the-road Tyre
Consimuction BIAS
Service Loader and Earthmover Service
Deeper tread depth provides excellent wear resistanceand longer service life.
Special compounds for exceptional wear and cut resistance.
Directional tread pattern for excellent power transfer inforward operation.
| Size | Ply rating | TRA code | Rim | Section width (mm) | Overall diamter (mm) | Tread depth (mm) | 10km/h | 50km/h | Type | ||
| Load capacity（kg） | Inflation pressure（kPa） | Load capacity（kg） | Inflation pressure（kPa） | ||||||||
| 16/70-20 | 10 | L-3 | 13(SDC) | 410 | 1075 | 20 | - | - | 2400 | 250 | TT |
| 16/70-20 | 14 | L-3 | 13(SDC) | 410 | 1075 | 20 | 5150 | 450 | - | - | TT |
